deployment mysql standalone

kubernetes 集群內部署 單節點 mysql

ansible all -m shell -a "mkdir -p /mnt/mysql/data"

cat mysql-pv-pvc.yaml

apiVersion: v1
kind: PersistentVolume
metadata:
  name: mysql-pv-volume
  labels:
    type: local
spec:
  storageClassName: manual
  capacity:
    storage: 5Gi
  accessModes:
    - ReadWriteOnce
  hostPath:
    path: "/mnt/mysql/data"
---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: mysql-pv-claim
spec:
  storageClassName: manual
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 5Gi

cat mysql-deploy.yaml

apiVersion: v1
kind: Service
metadata:
  name: mysql
spec:
  type: NodePort
  ports:
  - port: 3306
    nodePort: 30006
    targetPort: 3306
    protocol: TCP
  selector:
    app: mysql
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: mysql
spec:
  selector:
    matchLabels:
      app: mysql
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: mysql
    spec:
      containers:
      - image: mysql:5.7
        name: mysql
        env:
          # Use secret in real usage
        - name: MYSQL_ROOT_PASSWORD
          value: password
        ports:
        - containerPort: 3306
          name: mysql
        volumeMounts:
        - name: mysql-persistent-storage
          mountPath: /var/lib/mysql
      volumes:
      - name: mysql-persistent-storage
        persistentVolumeClaim:
          claimName: mysql-pv-claim

注意：如果使用 image: mysql:8.0 以上 需要 添加MYSQL_SERVICE_DB_PARAM修改characterEncoding=utf8&connectTimeout=1000&socketTimeout=3000&autoReconnect=true&useUnicode=true&useSSL=false&serverTimezone=Asia/Shanghai

start:

kubectl apply -f mysql-pv-pvc.yaml
kubectl apply -f mysql-deploy.yaml

check

[root@kube-master01 mysql]# kubectl get pod
NAME                     READY   STATUS    RESTARTS   AGE
mysql-794c6d56c6-xnfhb   1/1     Running   0          10h
[root@kube-master01 mysql]# kubectl get svc
NAME         TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)          AGE
kubernetes   ClusterIP   10.43.0.1      <none>        443/TCP          23d
mysql        NodePort    10.43.17.172   <none>        3306:30006/TCP   10h
mysql        NodePort    10.43.17.172   <none>        3306:30006/TCP   10h
[root@kube-master01 mysql]# mysql -h 192.168.23.31 -P 30006 -u root -p'password'
mysql: [Warning] Using a password on the command line interface can be insecure.
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 15
Server version: 5.7.43 MySQL Community Server (GPL)

Copyright (c) 2000, 2023, Oracle and/or its affiliates.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> show databases
    -> ;
+--------------------+
| Database           |
+--------------------+
| information_schema |
| clusterpedia       |
| mysql              |
| performance_schema |
| sys                |
+--------------------+
5 rows in set (0.05 sec)

mysql>

statefulset mysql standalone

在kube-node01 創建目錄/mnt/mysql/data

mkdir -p /mnt/mysql/data

創建 pv & pvc

$ vim mysql-pv-pvc.yaml
apiVersion: v1
kind: PersistentVolume
metadata:
  name: mysql-pv-volume
  labels:
    type: local
spec:
  nodeAffinity:
    required:
      nodeSelectorTerms:
      - matchExpressions:
        - key: mysql.standalone.node
          operator: In
          values:
          - enable
  storageClassName: manual
  capacity:
    storage: 5Gi
  accessModes:
    - ReadWriteOnce
  hostPath:
    path: "/mnt/mysql/data"
---
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: mysql-pv-claim
  namespace: mysql
spec:
  storageClassName: manual
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 5Gi

創建 statefulset

$ vim mysql-deploy.yaml
apiVersion: v1
kind: Service
metadata:
  name: mysql
  namespace: mysql
spec:
  type: NodePort
  ports:
  - port: 3306
    nodePort: 30006
    targetPort: 3306
    protocol: TCP
  selector:
    app: mysql
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: mysql
  namespace: mysql
spec:
  selector:
    matchLabels:
      app: mysql
  template:
    metadata:
      labels:
        app: mysql
    spec:
      affinity:
        nodeAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            nodeSelectorTerms:
            - matchExpressions:
              - key: mysql.standalone.node
                operator: In
                values:
                - enable
      containers:
      - image: mysql:5.7
        name: mysql
        env:
          # Use secret in real usage
        - name: MYSQL_ROOT_PASSWORD
          value: password
        ports:
        - containerPort: 3306
          name: mysql
        volumeMounts:
        - name: mysql-persistent-storage
          mountPath: /var/lib/mysql
      volumes:
      - name: mysql-persistent-storage
        persistentVolumeClaim:
          claimName: mysql-pv-claim

執行：

kubectl apply -f mysql-pv-pvc.yaml
kubectl apply -f mysql-deploy.yaml

檢查

$ kubectl get all -n mysql
NAME          READY   STATUS    RESTARTS   AGE
pod/mysql-0   1/1     Running   0          5m16s

NAME            TYPE       CLUSTER-IP     EXTERNAL-IP   PORT(S)          AGE
service/mysql   NodePort   10.102.59.69   <none>        3306:30006/TCP   4m47s

NAME                     READY   AGE
statefulset.apps/mysql   1/1     5m16s

連接 mysql

[root@kube-master01 mysql-yaml]# mysql -h 192.168.23.21 -u root  -P 30006  -p'password'
mysql: [Warning] Using a password on the command line interface can be insecure.
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 4
Server version: 5.7.36 MySQL Community Server (GPL)

Copyright (c) 2000, 2023, Oracle and/or its affiliates.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> show databases;
+--------------------+
| Database           |
+--------------------+
| information_schema |
| mysql              |
| performance_schema |
| sys                |
+--------------------+
4 rows in set (0.01 sec)

helm install mysql standalone

• https://github.com/bitnami/charts/tree/main/bitnami/mysql
• https://github.com/upmio/infini-scale-install/tree/main/addons/mysql-standalone

1. 設置必要的環境變量

• DB_USER：登錄 MySQL 用戶名。

• DB_PWD：登錄 MySQL 用戶密碼。

• DB_STORAGECLASS_NAME：指定Storageclass名稱, 使用 kubectl get storageclasses 獲取可用的 Storageclass 名稱。

• DB_PVC_SIZE_G：指定持久化卷的大小，單位為Gi。

• DB_NODE_NAMES：指定安裝MySQL pod的節點名稱，節點名稱可以使用","作為分隔符，表示多個節點名稱，安裝程序會對節點進行l(wèi)abel固定安裝節點。

export DB_USER="admin"
export DB_PWD='password'
export DB_STORAGECLASS_NAME="topolvm-provisioner"
export DB_PVC_SIZE_G="50"
export DB_NODE_NAMES="db-node01,db-node02,db-node03"

2. 運行安裝腳本

注意??：如果找不到 Helm3，將自動安裝。

注意??：安裝腳本會對指定節點進行添加label的操作。

運行安裝腳本

curl -sSL https://raw.githubusercontent.com/upmio/infini-scale-install/main/addons/mysql/install_el7.sh | sh -

等幾分鐘。 如果所有 mysql pod 都在運行，則 mysql 將成功安裝。

$ kubectl get all  -n mysql
NAME          READY   STATUS    RESTARTS   AGE
pod/mysql-0   1/1     Running   0          113m

NAME            TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)    AGE
service/mysql   ClusterIP   None         <none>        3306/TCP   113m

NAME                     READY   AGE
statefulset.apps/mysql   1/1     113m

參考：文章來源地址http://www.zghlxwxcb.cn/news/detail-686376.html

• Run a Single-Instance Stateful Application
